Descripción
Aircraft
Takeoff Weight (with propellers)
1219 g*
Takeoff Weight (with Low-Noise propellers)
1229 g*
Max Takeoff Weight
Standard Propellers: 1420 g
Low-Noise Propellers: 1430 g
Dimensions
Folded: 260.6×113.7×138.4 mm (L×W×H)
Unfolded: 307.0×387.5×149.5 mm (L×W×H)
Maximum dimensions excluding propellers.
Max Payload
200 g
Propeller Size
10.8 in
Diagonal Wheelbase
438.8 mm
Max Ascent Speed
10 m/s
Maximum Ascent Speed With Accessories
6 m/s
Max Descent Speed
8 m/s
Max Descent Speed With Accessories
6 m/s
Max Horizontal Speed (at sea level, no wind)
21 m/s
21 m/s flying forward, 18 m/s flying backward, 19 m/s flying sideways
Max Altitude
6000 m
Max Operating Altitude with Payload
4000 m
Max Flight Time (without wind)
49 min (standard propellers)
46 min (low-noise propellers)
Measured with the aircraft flying at approximately 9 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment. Please pay attention to reminders in the app.
Max Hover Time (without wind)
42 min (standard propellers)
39 min (low-noise propellers)
Measured by the aircraft hovering in a windless environment at sea level, from 100% battery level until 0%.
Max Flight Distance (no wind)
35 km (standard propellers)
32 km (low-noise propellers)
Measured with the aircraft flying at approximately 14 m/s without payloads in a windless environment until the battery level reached 0%. Data is for reference only. Actual usage time may vary depending on the flight mode, accessories, and environment. Please pay attention to reminders in the app.
Max Wind Speed Resistance
12 m/s*
Max Pitch Angle
35°
Operating Temperature
GNSS
GPS + Galileo + BeiDou + GLONASS*
Hovering Accuracy Range (windless or breezy)
±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
RTK GNSS Accuracy
RTK Fix:
1 cm + 1 ppm (horizontal), 1.5 cm + 1 ppm (vertical)
Internal Storage
N/A
Ports
E-Port interface × 1: Supports official accessories and third-party PSDK devices (hot-swapping is not supported)
E-Port Lite interface × 1: supports USB connection to DJI tuning software and some third-party PSDK devices.
Accessories or expansion modules must be installed before powering on.
Propeller Model
1157F (standard propellers)
1154F (low noise propeller)
Beacon
Built into the aircraft
Camera
Image Sensor
DJI Matrice 4T
Wide:
1/1.3-inch CMOS, Effective Pixels: 48 MP
Medium Tele Camera:
1/1.3-inch CMOS, Effective Pixels: 48 MP
Telephoto:
1/1.5-inch CMOS, Effective Pixels: 48 MP
DJI Matrice 4E
Wide:
4/3-inch CMOS Effective Pixels: 20 MP
Medium Tele Camera:
1/1.3-inch CMOS, Effective Pixels: 48 MP
Telephoto:
1/1.5-inch CMOS, Effective Pixels: 48 MP
Lens
DJI Matrice 4T
FOV: 82°
Equivalent Focal Length: 24 mm
Aperture: f/1.7
Focus: 1 m to 8
DJI Matrice 4E
FOV: 84°
Equivalent Focal Length: 24 mm
Aperture: f/2.8-f/11
Focus: 1 m to 8
Medium Tele Camera
FOV: 35°
Equivalent Focal Length: 70 mm
Aperture: f/2.8
Focus: 3 m to 8
Tele camera
FOV: 15°
Equivalent Focal Length: 168 mm
Aperture: f/2.8
Focus: 3 m to 8
ISO Range
Normal Mode: ISO 100 to ISO 25600
Night Scene Mode:
Matrice 4T:
Wide Camera: ISO 100 to ISO 409600
Midum Tele Camera: ISO 100 to ISO 409600
Tele Camera: ISO 100 to ISO 819200
Matrice 4E:
Wide Camera: ISO 100 to ISO 204800
Midum Tele Camera: ISO 100 to ISO 409600
Tele Camera: ISO 100 to ISO 409600
Shutter Speed
DJI Matrice 4T
2-1/8000 s
DJI Matrice 4E
Wide:
Electronic Shutter: 2-1/8000 s
Mechanical Shutter: 2-1/2000 s
Medium Telephoto: 2-1/8000 s
Telephoto: 2-1/8000 s
Max Photo Size
DJI Matrice 4T
Wide: 8064 × 6048
Medium Telephoto: 8064 × 6048
Telephoto: 8192 × 6144
DJI Matrice 4E
Wide: 5280 × 3956
Medium Telephoto: 8064 × 6048
Telephoto: 8192 × 6144
Minimum Photo Interval
DJI Matrice 4T: 0.7 s
DJI Matrice 4E: 0.5 s
Still Photography Modes
DJI Matrice 4T:
Wide:
Single: 12 MP/48 MP
Interval: 12 MP/48 MP
JPEG:0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting:12MP
Panorama: 12 MP (raw image);100 MP (stitched image)
Medium Tele Camera:
Single: 12 MP and 48 MP
Interval: 12 MP/48 MP
JPEG:0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting: 12MP
Telephoto:
Single: 12 MP and 48 MP
Interval: 12 MP/48 MP
JPEG:0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting:12MP
DJI Matrice 4E:
Single: 20 MP
Interval: 20 MP
JPEG:0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
JPEG + RAW:2/3/5/7/10/15/20/30/60 s
Smart Shooting: 20 MP
Panorama: 20 MP (raw image);100 MP (stitched image)
Medium Tele Camera:
Single: 12 MP and 48 MP
Interval: 12 MP/48 MP
JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting:12 MP
Telephoto:
Single: 12 MP and 48 MP
Interval: 12 MP/48 MP
JPEG: 0.5/0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting: 12 MP
Video Codec and Resolution
Video Coding Format: H.264/H.265
Coding Strategy: CBR, VBR
Resolution:
4K: 3840 × 2160@30fps
FHD: 1920 × 1080@30fps
Max Video Bitrate
H.264: 60Mbps
H.265: 40Mbps
Supported File System
exFAT
Photo Format
DJI Matrice 4T: JPEG
DJI Matrice 4E:
Wide: JPEG/DNG (RAW)
Medium Tele Camera: JPEG
Telephoto: JPEG
Video Format
MP4 (MPEG-4 AVC/H.264)
Digital Zoom
Telephoto:
16x (112x hybrid zoom)
NIR Auxiliary Light
Infrared Illumination
DJI Matrice 4T:
FOV: 5.7°±0.3°
Laser Module
Laser Rangefinding
Measurement Range: 1800 m (1 Hz) @20% reflectivity target*
Oblique Incidence Range (1:5 Oblique Distance): 600 m (1 Hz)
Blind Zone: 1 m
Distance Measurement Accuracy:
1-3 m: System Error <0.3 m, Random Error <0.1 meters @1s
Other Distances: ±(0.2+0.0015D) (D represents the measurement distance in meters)
Infrared Thermal Camera
Thermal Imager
DJI Matrice 4T: uncooled vanadium oxide (VOx)
DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or a laser beam. Otherwise, the camera sensor may be burned leading to permanent damage.
Resolution
DJI Matrice 4T: 640 × 512
Pixel Pitch
DJI Matrice 4T: 12 µm
Frame Rate
DJI Matrice 4T: 30 Hz
Lens
DJI Matrice 4T DFOV: 45°±0.3°
DJI Matrice 4T equivalent focal length: 53 mm
DJI Matrice 4T Aperture: f/1.0
DJI Matrice 4T Focus: 5 m to 8
Sensitivity
DJI Matrice 4T: =50mk@F1.0
Temperature Measurement
- The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
- The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
- Max wind speed resistance during takeoff and landing.
- 10? to 40? (14°F to 104°F)
- GLONASS is supported only when the RTK module is enabled.
- Performance degradation may occur in rainy or foggy conditions
